The DTC1500 offers the convenience at low cost along with comprehensive features while still providing innovative protection that will help you issue highly secure identification cards more efficiently than ever before! With a lower cost and more convenient option, DTC1500 delivers on the needs of organizations. It’s highly secure while being easy to use with its innovative features that help you reduce time spent managing cards.
51405 Dual Sided ID Card Printer
The DTC1500 offers the convenience and lower cost of high-capacity consumables along with a comprehensive feature set and innovative, easy-to implement security elements — enabling organizations to routinely issue highly secure cards and IDs at a fraction of the cost without sacrificing quality.
KEY FEATURES: • Innovative, built-in security features – Easy-to-implement security features such as resin scramble data protection and custom overlay watermark come standard on every unit • Low-cost, high-capacity consumables – High-capacity, full- and half-panel color ribbons significantly lower cost-per-card and reduce total cost of ownership • Highly versatile – Powerful printing in a modular, scalable design that simplifies in-field equipment upgrades and migration to higher levels of security • Earth friendly – GreenCircle® Certified for efficient energy consumption and eco-friendly (ECO) refill ribbons
Print Method Dye sublimation / resin thermal transferResolution300 dpi (11.8 dots/mm) continuous tone Colors
Up to 16.7 million / 256 shades per pixel Print Ribbon Options
Wide array of eco-friendly, high-capacity print ribbons from K to YMCKOKO. Laminate patch options from full card coverage and half panel polyester overlaminates to off-the-shelf and fully custom holographic overlaminates are all available from HID. Available print ribbons include:• Full-color with resin black and overlay panel, YMCKO*, 500 prints • Full-color with two resin black panels and overlay panel, YMCKOK*, 500 prints• Full-color with two resin black panels, YMCKK*, 500 prints• Full-color half-panel with resin black and overlay panel, YMCKO*, 850 prints• Full-color half-panel with two resin black panels and overlay panel, YMCKOK*, 650 prints• Full-color half-panel with two resin black panels and overlay panels, YMCKOKO*, 500 prints• Resin black, K*, 3000 prints
Print Speed**6 seconds per card (K*); 16 seconds per card (YMCKO*); 24 seconds per card (YMCKOK*)Accepted Standard Card SizesCR-80 (3.375˝L x 2.125˝W / 85.6 mm L x 54 mm W); CR-79 (3.313″ L x 2.063″ W / 84.1 mm L x 52.4 mm W) Print AreaCR-80 edge-to-edge (3.36˝L x 2.11˝W / 85.3 mm L x 53.7 mm W); CR-79 (3.3″ L x 2.04″ W / 83.8 mm L x 51.8 mm W)Accepted Card Thickness.009˝ – .040˝ / 9 mil – 40 mil / .229 mm – 1.016 mm
Accepted Card Types
PVC or polyester cards with polished PVC finish; 100% polyester cards (monochrome resin required); rewrite
Input Hopper Card Capacity100 cards (.030˝ / .762 mm)Output Hopper Card Capacity
Up to 100 cards. (.030″ / .762 mm) Card
Cleaning Card cleaning roller integrated into ribbon cartridge; cleaning roller is automatically replaced with each ribbon changeMemory32 MB RAM
Windows® 7, 8, 8.1 and 10 (32 bit & 64 bit) / Windows Server 2003, 2008, 2012 / Linux****Interface
USB 2.0, Standard Ethernet with internal print server (Ethernet is optional on BIS-certified units)Operating Temperature65° to 80° F / 18° to 2
